Introduction:

Cantilever shelves are an important type of shelf. Cantilever shelves are suitable for storing long materials, ring materials, plates, pipes and irregular goods. The cantilever can be single-sided or double-sided. The cantilevered shelf has the characteristics of stable structure, good load carrying capacity and high space utilization. The cantilever shelf pillars are mostly H-shaped steel or cold-rolled steel. The cantilever is square tube, cold-rolled steel or H-shaped steel. The cantilever and the column are inserted or bolted. The base and the column are bolted and the base is cold. Rolled steel or H-beam.

Cantilever shelves are constructed by mounting cantilever on the column. The cantilever can be fixed or mobile. Pipes and plates are used for storage. According to the carrying capacity, it can be divided into three types: light weight, medium weight, and heavy weight. According to the structure, it can be divided into single-sided cantilever shelves and double-sided cantilever shelves.

Structural features:

1).The cantilever can be single-sided or double-sided. The cantilevered shelf has the characteristics of stable structure, good load carrying capacity and high space utilization. Access to goods is carried out by forklifts, trucks or humans.

2).Cantilevered shelves are usually within 2.0 meters in height (for example, up to 6 meters when accessed by a forklift truck). The cantilever length is within 1.5 meters and the load per arm is usually within 800KG.

The use of shelves:

Cantilever shelves are suitable for storing long materials, ring materials, plates, pipes and irregular goods. The cantilever shelf pillars are mostly H-shaped steel or cold-rolled steel. The cantilever is square tube, cold-rolled steel or H-shaped steel. The cantilever and the column are inserted or bolted. The base and the column are bolted and the base is cold. Rolled steel or H-beam. Access to goods is carried out by forklifts, trucks or humans. Shelf height is usually within 2.5 meters (such as up to 6 meters if the truck is accessed by a forklift), the cantilever length is within 1.5 meters, and the load per arm is usually within 1000KG. This kind of shelf is mostly used in the machinery manufacturing industry and building materials supermarkets. With the addition of shelves, it is particularly suitable for small space, low height warehouses, easy management, wide field of vision, compared with ordinary shelf-type shelves, the utilization rate is higher; according to the carrying capacity can be divided into lightweight, medium-sized, weight Type three.

For storage of bulky, fragmented or other special products, cantilevered shelves are the ideal solution. Cantilevered shelves are divided into single arm and two arms, efficient storage of wood, pipe, strips and other similar products. Cantilevered shelves are The traditional shelf rack is equipped with an outer cantilever. It is a special shelf for long objects.

Application:

Cantilevered shelves are mostly used in machinery manufacturing and building materials supermarkets. With the addition of shelves, it is particularly suitable for small, low-rise warehouses, easy management, wide field of vision, and higher utilization than ordinary shelves.

Packing and shipping:

1). Commonly load in 20ft container and 40HQ container;

2). Surface been covered with plastic dustproof film;

3). Steel Strip fixed;

4). Special protection brown paper cover two ends optional.
